250lik Mesin Molding Molding

Model:KGB120E

Open tetep lan nutup mesin ngeculke jotosan, nampilake rod tikel sinkronisasi rod lan silinder langsung Milih Milih Milih, ngirim katrangan lan efisiensi sing dhuwur. Dilengkapi sistem servo hydrallic kanggo nanggepi cepet lan tabungan energi, mesin cetakan jotosan 250L sing luwih apik kanggo ngasilake macem-macem produk, saka kontaner sing luwih cilik.

Jilid: 250LBobot: 28T

Kirim Pitakonan

Deskripsi Produk Specification Application

Model standar KGB120E, mesin ngeculke sirah sing misuwur lancum, Kalebu pengontrol Kebalihan 100 Kebalur, lengen robot, lan bledosan ngisor Sistem, nambah produktivitas lan kualitas. Mesin ngeculke versailile iki luwih apik Kanggo macem-macem aplikasi, kalebu mesin ngecor gendang kimia Solusi, palet plastik jotosan proses mesin ngecor, banyu plastik Aplikasi Mesin Tank Blow, lan produksi 200-220l Tong dering kaping pindho, tank tank, bagean otomatis, alangan lalu lintas, obat Perabot, kursi, meja, meja, palet, prau, lan liya-liyane.

Fitur lan Keuntungan

Digunakake kanggo produk manufaktur ing macem-macem industri. Apa ana kontaner sing tahan karat ing industri kimia, botol kemasan kanthi standar kabangsa ing industri panganan, utawa kothak kemasan kanthi penampilan sing nyenengake kanggo produk sing beda-beda.
Proses pemakaran nganggo teknologi pemotong lan dioptimalake adhedhasar karakteristik produksi kapasitas kapasitas ing mesin 120e jotosan jotosan 120e. Prentah kanthi akurat tarif lan distribusi bahan mentah kanggo njamin ketebalan tembok seragam sajrone ngecat produk volume ultra, lan ngilangi cacat kualitas sing disebabake dening panganan sing ora rata.

250L accumulate blow molding machine

Specifications

Serial number	Material PE、PP、ABS...	Mold closing oil cylinder(single cylinder)
Serial number	Material PE、PP、ABS...	Machine model:KGB120E
Specifications
1	Max container capacity	250 L
2	Output(dry Cycle)	300 PC/HR
3	Machine Dimension(L×W×H)	7.6 M x 4.3 M x5.5 M
4	Machine weight	28 T
Clamping Unit
1	Clamping force	800 KN-1200 KN
2	Mold platen size(W×H)	1300 MM x 1400MM
3	Platen opening stroke	800 MM-1800 MM
4	Platen moving stroke	700 MM
5	Max mold size(W×H)	1100 MM x 1700 MM
6	Mold thickness	810 MM - 900 MM
Power
1	Servo oil pump motor power	37 KW
2	Servopump displacement	250 L/MIN
3	Blow pressure	0.8 Mpa
4	Air consumption	1.8 M³/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	120 L/min
7	Average energy consumption	80 KW -90 KW
Extruder unit
1	Screw diameter	120 MM
2	Screw L/D ratio	25 L/D
3	HDPEMelting capacit for HDPE	250 Kg/hr-320 Kg/hr
4	Number of heating zone	6 ZONE
5	Screw heating power	30.2 KW
6	Screw fan power	0.6 KW
7	Extruder motor power	90(110) KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	38.8 KW
3	Max die-pin diameter	600(700) MM
4	Accumulator capacity	20(25) L
5	(PE)Accumulator weight	15(18) KG
