10l nglumpukake mesin campuran jotosan

Model:KGB70A

KGB70A minangka mesin modha sing serbaguna 10L sing dirancang kanggo Molding Botol Botol 15 liter. Minangka pabrikan mesin botol banyu utama, kita nawakake solusi khusus kanggo nyukupi syarat pelanggan. Mesin kasebut ora mung kanggo botol banyu, kontaner pestisida, lan produksi kemasan kimia, nanging uga produk sing cilik nanging khusus. Mesin iki butuh macem-macem kabutuhan.

Jilid: 20LBobot: 7.8T

Kirim Pitakonan

Deskripsi Produk Specification Application

KGB7TA 10L Mesin Molding Nerbitake minangka pambukaan lan nutup Model, sing nganggo Mekanisme Clamping kaping pindho tarik rod, minyak Tekanan Langsung Silinder Ngunci Mold, lancar Silinder mati kepala. Kontrol sistem servo hydrallic, kacepetan respon cepet lan ngirit energi.
Liyane Suite kanggo Produksi Produk Wangun Khusus kasebut, bisa Ngontrol bentuk lan kekandelan luwih akurasi.

Fitur lan Keuntungan

Model iki minangka cetakan sing mbukak lan nutup cetakan, nggunakake mekanisme nutup film synchronous synchronous, lan tekanan langsung silinder langsung ngunci cetakan
● silangan silinder silinder mati seri
● volume maksimal 20l
● Cocog kanggo botol banyu, kontaner pestisida, lan kemasan kimia saben dina, lsp.
● Fitur sing khas yaiku dikontrol dening sistem servo hidrolik kanggo entuk tanggapan aksi kanthi cepet lan efisiensi energi dhuwur.

Specifications

serial number	Material PE、PP、ABS ...	Mold closing oil cylinder(single cylinder)
serial number	Material PE、PP、ABS ...	Machine model:KGB70A
Specifications
1	Max container capacity	20L
2	Output(dry Cycle)	700 PC/HR
3	Machine Dimension(L×W×H)	4.3 M x1.7 M x3.9 M
4	Machine weight	7.8 T
Clamping Unit
1	Clamping force	130 KN
2	Mold platen size(W×H)	680 MM x 600 MM
3	Platen openingstroke	300 MM - 850 MM
4	Platen moving stroke	370 MM
5	Max mold size(W×H)	460 MM×600 MM
6	Mold thickness	310 MM - 380 MM
Power
1	Servooil pump motor power	11KW
2	Servo pump displacement	80 L/MIN
3	Blowpressure	0.8 Mpa
4	Air consumption	0.7 M²/MIN
5	Cooling water pressure	0.3 Mpa
6	Water consumption	60 L/min
7	Average energy consumption	18 KW-22 KW
Extruder unit
1	Screw diameter	70 MM
2	Screw L/D ratio	24 L/D
3	Melting capacit for HDPE	80 Kg/hr
4	Number of heating zone	3 ZONE
5	Screw heating power	12.6 KW
6	Screw fanpower	0.5 KW
7	Extruder motor power	22 KW
Die head
1	Number of heating sections	5 ZONE
2	Heating power	20 KW
3	Maxdie-pin diameter	180 MM
4	Accumulator capacity	3 L
5	(PE)Accumulator weight	2.25 KG
